loop heat pipes for
Data center servers

lhp-DCs

A passive solution capable of cooling the latest high performance processors.
No water No risk

Calyos uses a dielectric, safe, and green refrigerant inside our systems. This removes the risk of short circuiting expensive equipment if the lines are damaged.

high heat flux ready

Our systems are built for the latest components and can handle heat-flux hotspots up to 250W/cm². Calyos is developing solutions to take this even further.

easy to adopt

Combining standard components with custom lines to suit your mechanical design ensures our system can be adopted on both new or existing hardware.

fit & forget

With no moving parts, our solutions are extremely reliable and inherently maintenance free. Therefore they are ideal for reliability critical environments.

100% PASSIVE

The beauty of two-phase is the ability to harness the latent heat of vaporization, using it to power the cooling system, making it the most sustainable solution.

LHP-DCS

Adapt the system to your needs

No application is the same, hence each of our solutions is adaptable to the your specific needs and design. Below we outline how several key parts of the solution can be modified to suit the thermal challenge you face.

The Evaporator

If you have multiple heat sources we can add extra evaporators as needed, combining them into one complete system. Calyos can also adapt the size of the mounting plate to suit the component socket or PCB design.

The LINES

The lines join the evaporator to the condenser. They can also integrate multiple evaporators in parallel if needed. Their route, direction, and length can easily be customised. Flexible sections are typically included to ease maintenance and installation.

the condenser

Calyos can use any size of air exchanger, located anywhere within the server. Accessing remote locations can improve the performance thanks to better airflow. Calyos can also use a liquid to liquid exchanger at the back of the server chassis for heat recovery.

LHP-DCS

USE CASES

There are thousands of use cases for our technology. Here we have selected a few typical applications. Don't be afraid if you have something different - reach out to us and we can validate the application through feasibility study.

request feasibility study
Here Calyos was targeting two 350W CPUs inside a 1U server chassis. The design was optimized for 75 CFM, ensuring quiet operation.

2x CPU

Compute

:

Server

Here Calyos was targeting two 350W CPUs inside a 1U server chassis. The design was optimized for 75 CFM, ensuring quiet operation.
Here a very low case temperature was targeted for a 300W FPGA in a 1U chassis by transporting the heat to an area where the air exchanger size and airflow can be maximized.

1x FPGA

Compute

:

Server

Here a very low case temperature was targeted for a 300W FPGA in a 1U chassis by transporting the heat to an area where the air exchanger size and airflow can be maximized.
Here one 600W CPU, with >150W hotspots, is inside a 2U chassis with 300CFM of airflow. Transporting the heat to the rear of the chassis enabled maximum airflow.

1x CPU

Compute

:

Server

Here one 600W CPU, with >150W hotspots, is inside a 2U chassis with 300CFM of airflow. Transporting the heat to the rear of the chassis enabled maximum airflow.

LHP-DCs

Production Status

Calyos strives to meet the cost target for each application, whether it be through our own production or licensing the technology to a partner.

Low Volume

<10k units per year

Production ready

Calyos already produces LHP-DCS solutions for a variety of server applications. To evaluate our solution fill in our feasibility form.

Mid volume

10-100k units per year

launching soon

Calyos is preparing our supply chain to produce for mid volume applications in the near future. Reach out to us if you would like to know more.

high volume

>100k units per year

under development

Looking further forward Calyos is working with partners to license our technology for production in mass market applications.

do you want to compare a Calyos solution?

As our solutions are adapted specifically to your application, Calyos offers a free feasibility study providing you with estimates for the thermal performance, mechanical design, and cost, enabling you to directly compare against your current solution.
